DS1093-162A 75
5 1093/004AHD 1093/008AHD AND 1093/016AHD SPECIFICATIONS (PAL FORMAT)
Feature
Characteristics
1093/004AHD 1093/008AHD 1093/016AHD
Compression formats Video: H.264 / Audio: 8kHz*16bit ADPCM
Video Inputs/outputs
4-CH BNC Input/
1 CH VGA Output
1 CH HDMI Output
8-CH BNC Input/
1 CH VGA Output
1 CH HDMI Output
16-CH BNC Input/
1 CH VGA Output
1 CH HDMI Output
Audio I/O 4-CH RCA Input / 1-CH RCA Output
Display Resolution/ Frame rate 720P: 1280×720@25fps for Single Channel
Recording resolution
720P (1280x720)
8), WHD1(960x288), WD1(960x576)
Recording frame rate
100fps@720P,
100fps@WD1,
100fps@WHD1,
100fps@WCIF
200fps@720P,
200fps@WD1,
200fps@WHD1,
200fps@WCIF
400fps@720P,
400fps@WD1,
400fps@WHD1,
400fps@WCIF
Recording modes Always / Timed / Manual /Motion Detection
Always / Timed /
Manual /Motion
Detection / Sensor or
External Alarms
Sub Stream CIF@ No Real Time
Hard Disk Interface Max 1 Sata HDD
Memory for video backup
Hard Disk 1000 GB (default)
USB External Device/ Network (AVI files)
Playback modes PLAY /SLOW /FWD/Frame by Frame
Syncronous Playback
4ch.
1. 720P:25fps (1CH)
2. 720P:15fps (4CH)
3.WD1/WHD1/WCIF:
25fps (4CH)
8ch.
1. 720P: 25fps (1CH)
2. 720P: 15fps (8CH)
3.WD1/WHD1/WCIF:
25fps (8CH)
16ch.
1. 720P: 25fps (1CH)
2. 720P: 15fps (16CH)
3.WD1/WHD1/WCIF:
25fps (16CH)
Watermark/ Web Data Encryption YES
Web / Client Software Multi - Language
Browser and O.S. Supported: Internet Explorer 11.0 for Windows 7 and
above and Safari 6.0 for MAC 10.8.0 or above
Client Software Supported: Urmet UVS
I/O alarm NO
4-CH alarm inputs,
1-CH alarm output
Alarm types Motion/ Video loss / HD space / HD failure
Motion/ External
alarms / Input alarms /
Video loss / HD space /
HD failure
Maximum number of PC that can be
connected simultaneously
3
PDA Software Mobile Urmet iUVS (iOS, Android)
PTZ Control By RS485 using PELCO-D and PELCO-P protocol
USB 2.0 port Support mouse
Ethernet RJ-45 10M/100MB self-adaptable Interface
Network protocols TCP/IP, DHCP, UDP, Urmet DDNS with ID, P2P, PPPOE
Power consumption 10W
Power supply 12V / 2A
Operating temperature range 5°C – 40°C
Dimensions (width x height x depth) 300X53X227 mm
Weight ~3 kg
