VAT 613 Series User Manual

Series 613 OPERATION
984360EC Edition 12.08.2022 117/
149
Parameter:
Location: CPA/Navigation/Parameters: Pressure Control.General Settings.Automated Controller
Selector
Parameter Description
Enable Switches on/off the function
Mode
Threshold
Pressure Direction
Controller Selector Bitmap
Used if Mode = Threshold
Defines which controllers are automatically selected
Threshold Condition
Used if Mode = Threshold
Lower or Equal
Equal
The Thresholds are related to Target Pressure
Controller 1 Threshold
Controller 2 Threshold
Controller 3 Threshold
Controller 4 Threshold
Used if Mode = Threshold
The Thresholds are related to Target Pressure
Controller Pressure Rising
Controller Pressure Falling
Used if Mode = Pressure Direction
Select one Controller for up control and one for down control
Controller 1
Controller 2
Controller 3
Controller 4
6.3.8 Control Position Restriction
Location: CPA/Navigation/Parameters: Pressure Control.General Settings.Control Position Restriction
Parameter
Description
Enable
False
True
Minimum Control Position
Defines the lowest position during pressure control
Maximum Control Position
Defines the highest position during pressure control
Restriction Active
False
True
6.3.9 Store Control Parameter Volatile
Used when the control parameters are changed frequently during the process and it is not useful to
store the value in the non-volatile memory each time (the lifetime of the non-volatile value is 1 million
memory cycles).
Only effective on the interface, the settings via CPA are always stored in non-volatile memory
Location: CPA/Navigation/Parameters: Pressure Control.General Settings
Parameter Description
Store Control Parameter Volatile
False
True
