5.6 Power Up
After power up or possibly after a reset of the valve homing is necessary to determine the plate position.
Refer to chapter «5.11.2 Homing »
5.7 Power Down, Power Failure Option
5.7.1 Power down behavior in case of power failure
Valve position before power failure: Reaction of valve:
Closed (isolated) Valve remains closed.
Valve open or in any intermediate position The plate remains at the current position.
All parameters are stored in a power fail save memory.
5.7.2 Power Fail Option
Power Fail Option is circuit board that can store as much energy to close or open the valve in the event of
a power failure.
Technical data
Charging Time 2 minutes max.
Durability Up to 10 years @ 25°C ambient
These settings define what the valve is doing in case the power fails.
Valve must be equipped with the ‘Power Failure Option’
[61. . . - . . C . - . . . . or 61. . . - . . H . - . . . .]
For PFO retrofit and other options refer to chapter: «Spare parts».
Location: CPA/Navigation/Parameters: Power Fail Option
Parameter Description
Enable
‘True’ enables the power fail reaction.
‘False’ there is no reaction on a power fail
State
Battery is Charging
Ready to Use
Active
Failure
Functionality
Open
Close
Delay
In seconds
After this delay, the power failure reaction starts after the power failed.
Helps to bridge a short power interruption.
Battery Voltage
Shows state of charge
Power Fail Cycles
Counts Power Failure
