VAT 613 Series User Manual

TROUBLE SHOOTING Series
613
120/149 Edition 12.08.2022 984360EC
7 Trouble shooting
7.1 Warnings
A warning does not lead to an interruption of valve operation.
Location: CPA/Parameters: System.Services
Parameter Description
Warning Bitmap
Bit
Hex
Description
0
1
No learn data available for adaptive control
1
2
Position indicator signal of the external isolation valve incorrect.
2
4
No Sensor Active
3 8 PFO Not Ready
4 16 Cluster Slave Offline
6 40 Fieldbus Data Not Valid
8 256 Compressed Air Not Falling when valve close
9 512 Compressed Air Too Low
10 1024 Compressed Air Too High
12 4096 Fan stall alarm
