5.10 System Settings and States
5.10.1 Identification
5.10.1.1 Serial Number
Location: CPA/Parameters: System.Identifiaction.Serial Number
Parameter Description
Serial Number
VAT specific number
5.10.1.2 Configuration
Location: CPA/Parameters: System.Identifiaction.Configuration
Parameter Description
Valve Series
3-digit value representing the VAT valve series
Valve
Variant
For some vale there exists different variants
Nominal Diameter
DN in mm. E.g DN250
Drive Parameter ID
ID of the last drive file loaded on the valve.
Sets the parameters responsible for the movement characteristics of the
valve
Configuration
Parameters ID
ID of the last configuration file loaded on the valve.
Configuration of Interface, Pressure Control, Pressure Sensor, …
5.10.1.3 Firmware
Location: CPA/Parameters: System.Identification.Firmware
Parameter Description
Valve Firmware ID
VAT specific identification number
Valve Firmware Version
Faa.bb.cc.dd
a = Platform, Controller Type
b = Type Customer
Basis
Production
Test
c = Version
d = Revision
CPA Version
VAT PC software version
Interface Firmware Version
Network controller firmware
Motion Controller Firmware Version
Motion controller firmware
