VAT 613 Series User Manual

Series 613 INSTALLATION
984360EC Edition 12.08.2022 85/1
49
5.14.2 Digital Output
5.14.2.1 Connection
Pin Default Function
5
OUTPUT 1
Open
6
OUTPUT 2
Closed
7
COMMON
5.14.2.2 Parameter, Configuration
Location: CPA/Navigation/Parameters: Power Connector IO.Digital Output
Parameter Description
Enable
1
enables the output
State
0
Not active
1
Active
Functionality
0
OPEN valve is fully open
1 CLOSE valve is fully closed (isolated if valve has an isolation function)
2
HOLD valve is in hold state
Inverted
Function
State
Output
0
Not Inverted
inactive 0 Off
active
1
On
1
Inverted
inactive
1
On
active
0
Off
