VAT 613 Series User Manual

INSTALLATION Series
613
60/149 Edition 12.08.2022 984360EC
5.12.8 Compatible Command Sets
IC2 command syntax (p: command described above) is working independent from the
set compatible Command Set
Location: CPA\Parameters: Interface RS232/RS485.Command Set
Parameter
Description
Command Set
IC
First VAT integrated controller with RS232 Service Port
PM VAT PM controller
PM V2 VAT PM controller with sensor crossover
Tylan
These instruction sets are often used in controllers from
other manufacturers
Tylan Type 1
Tylan Type 2
5.12.8.1 Command Set IC
Note:
All position and pressure values are integer values and they are scalable:
Default range pressure 0 … 1000000
position 0 … 100000
Location: CPA/Parameters: Interface RS232/RS485.Scaling
Command Specific Setting
Location: CPA\Parameters: Interface RS232/RS485.Settings
Parameter
Description
R S Answer
Specifies response to R (set position) and S (set pressure) commands
Standard
Response is ‘R:’ or ‘S:’
i:76
Response is same as the i:76 request command, see below
System
Set
Resp
Get
Resp
Data
Set, Get Resp
Description
c:01
c:01
aa
Access Mode:
0=Local, 1=Remote, 2=Locked
i:80
i:80
abcdefgh
Hardware Configuration
a
Power Failure Option:
0=no, 1=yes
b
Sensor Power Supply:
0=no, 1=yes
c Interface Type:
2=RS232, 3=RS323 with AO, 8=RS232/RS485, 9=RS232/485 with AO
d Sensor Inputs: 0, 1 or 2
e
Cluster Option:
0=no, 1=yes
f
External Isolation Valve:
0=no, 1=yes
g
Reserved
h
Small Size Controller:
0=no, 1=yes
i:82 i:82 string Firmware
i:83
i:83
string
Serial Number
i:30 i:30 abcdeeef Device Status
a
Access Mode:
0=Local, 1=Remote, 2=Locked
b
Control Mode:
0=Init,1=Homing,2=Position,3=Close,4=Open,5=Pressure
Control,6=Hold,7=Learn,8=Interlock Open,9=Interlock Close,12=Power
Failure,13=Safety,14=Error
c
PFO Disabled:
0=no, 1=yes
d Warning Present: (in i:51 or i:52) 0=no, 1=yes
e
Reserved
f
Sensor Simulation Active:
0=no, 1=yes
