5.11 Valve Settings and States
5.11.1 States
Location: CPA/Navigation/Parameters: Valve
Parameter Description
Actual Position
Show position of the valve plate
Position State
Intermediate
Closed
Open
Isolation State
Not Isolated
Isolated
5.11.2 Homing
After power up or possibly after a reset of the valve homing is necessary to determine the plate position.
Location: CPA/Navigation/Parameters: Valve.Homing
Parameter Description
Start Condition
Homing start option defines when the valve performs the homing procedure.
Standard
Automatically if valve is not in sealed state,
otherwise it is waiting for a move command.
Open Command
On an open command
Move Command
On any move command
At Startup
All the time
Homing Command
On homing command
Move Command Without Close
On any move command except close
command if the valve is closed
End Control Mode
This control mode is set after a successful homing.
Position
Close
Open
Pressure Control
End Position
In case the
End Control Mode
is set to 2 (Position), this parameter defines
which position is set after successful homing.
Followed description of the standard setting:
Valve position before power up:
Reaction of valve:
Closed (isolated) Valve remains closed.
Homing will be done when first movement command is received.
All other than closed (not isolated)
Valve do homing to initialize position.
Display shows ‘Ho’ until homing is done
Valve position after homing is closed
