13.3 Control unit and Accessories
13.3.1 Control and actuating unit
Description Part number
Control and actuating unit Too many to list. Please contact VAT.
Option board with SPS module
(±15 VDC Sensor Power Supply)
858530
Option board with PFO module
(Power Failure Option)
858529
Option board
with SPS and PFO module
840512
13.3.2 Accessories
Description Part number
24 VDC power supply unit
(input: 100 – 240 VAC)
891528
(D-Sub15 connector)
Adapter cable for power supply with
D-Sub9 connector
(735567)
(D-Sub15 to D-Sub9)
Plug D-sub 15 pin female with 4-
40UNC screws for the power input
and Logic interface (plug only)
81177-R1
Service cable
(PC to valve Service connector)
809474
(USB A–B male-male)
Special Allen wrench (SW3) for
disassembly and assembly
244873
O-ring removal tool 234859
13.3.3 Centering ring with VITON ® O-ring
Description
Valve size
Product ordering number
DN
25
/ 1
61328 - . . . .
DN 40 / 1½”
61332 - . . . .
DN 50 / 2”
61334 - . . . .
Centering ring
with VITON ® O-ring
(for ISO-KF and ISO-
F installation only)
Aluminum 31028-KAZV-0001 31032-KAZV--0001 32034-KAZV-0001
Stainless steel 31028-KEZV-0001 31032-KEZV-0001 32034-KEZV-0001
