Introduction
Chapter 1: Introduction
SmartAisle2 is an intelligent, integrated infrastructure in a self-contained line-up solution that is easy to deploy
and tailored for large data centers and computer rooms. All data centers have distinct operation and business
objectives. Balancing the data center practices for capacity, space utilization, availability, and eiciency has been
tedious owing to the ever-increasing demand in the IT space.
Enter SmartAisle2 – an enclosed complete data center solution (referred to as SmartAisle2) in an indoor environment.
With Precision cooling, UPS, power management, monitoring and control technologies, and fire suppression
integrated into a holistic enclosed system, this smart solution is ideally suited for environments where dedicated
IT room improvements are neither practical nor cost-eective. It is flexible as it can be placed unobtrusively into
workspaces without the clutter or bulk associated with these kinds of solutions. It is highly eective, economical,
inter-operable, and makes use of the existing infrastructure or whitespace, avoids expensive room upgrades along
with the optional fire suppression system - all in one enclosed solution. This top-notch modular enterprise-grade
solution is unique and brings together industry-best practices and latest technologies to enable streamlined
management in a compact footprint.
It is an ideal solution tailored for 19” rack hardware device, including servers, voice data, Internet network equipment,
cabinets, closure assembly and power supply, cooling, monitoring equipment, bearer cabinets equipment and is
best suited for large data centers.
1.1. Configuration Specification for SmartAisle2
The typical configuration of the SmartAisle2 solution is shown in Table 1-1.
Table 1-1 Configuration
Parameter Specifications
Size
Corridor width 1200 mm
Machine external dimensions See Section 1.4.3
Overall key
indicators
Density levels Low-density
Power Architecture Centralized power supply
Cooling architecture
Air cooled DX based row cooling units, independent cooling
modules
Structured Cabling Column header network wiring closet
Fire architecture` External fire, borrow building
The total number of U-bit single module 1008 (single cabinet 42U, including the network cabinet)
Redundant power supply 2 N
The average power consumption of a
single cabinet
4 kW
IT power consumption single module 92 kW
Overall key
indicators
Single refrigeration module 105 kW
Altitude Less than 1000 m (air conditioning de-rating more than 1000 m)
Mounting Raised floor or ground installation
