Vertiv | SmartAisle2 | User Manual 79
Installation
2.9. Installation of the Air conditioning System
Sl. No. Details of Equipment
1 Base
2 Server Cabinet
3 Network Cabinet
4 Access door
5 Top Plate
6 A/C Column
7 Distribution Cabinet
8 Strong wire passage groove
9 Power cable trunking; copper and fiber cable tray
10 Cabinet top wire groove
11 Control panel
In this section, the overall layout of refrigeration, air conditioning, and the mechanical installation method is
explained in detail.
• To ensure safety of the front-line of the repaired welding joints, the pressure release system in the air con-
ditioning system should release clean nitrogen emissions.
To Next Page
