Vertiv | SmartAisle2 | User Manual 112
Installation
2.14. Total System Power Input
• Always disconnect the switch before installing the superior low voltage switchboard output power from
improper operation will result in the warranty becoming void as the customer is accountable.
• All power lines, connectors, and ground control must comply with the local regulations and protocols of the
region or country as it supersedes everything else.
• See the nameplate about the full load current. The cable should match the size of the local wiring rules.
• Electrical installation and maintenance work including repairs must be carried out by an authorized person-
nel.
As seen from the preceding figure, the power cables must be connected as follows:
• Input line, Neutral, and Ground cables in the cabinet.
• Fire-wire input is connected to the respective A-phase, B-Phase and C-phase input terminal.
• Input, neutral, and ground wires are connected to the zero row in the cabinet and ground rows.
