1-4 OM 25-3503 us – Edition 4.1 * * 2503_3503b110.fm
Introduction
1.4 Fields of application, attachments
The attachments will decide in the first place how the excavator is used.
In order to avoid damage to the machine, only the attachments listed below
have been certified for installation on the machine.
• Please contact your Wacker Neuson dealer if you wish to use other attach-
ments.
Using attachments other than Caterpillar, or using attachments that are to be used with
other excavator types, can reduce the machine’s output and stability considerably and
cause damage to the machine and injury.
Always compare the weight of the attachment and its maximum payload with the indica-
tions in the lift capacity table. Never exceed the maximum payload stated in the lift capac-
ity table.
Information!
Please refer to the Operator’s and maintenance manual of the attachment
manufacturer for using and performing maintenance on attachments such as
hammers, grabs, etc.
Use: attachment
2503 without quickhitch
Bucket type
Width Capacity Weight
Bucket 260 mm (10 in)
0.036 m
3
(1.27 ft
3
)
38 kg (84 lbs)
Bucket 300 mm (12 in)
0.043 m
3
(1.52 ft
3
)
41 kg (90 lbs)
Bucket 400 mm (16 in)
0.059 m
3
(2.08 ft
3
)
48 kg (106 lbs)
Bucket 500 mm (20 in)
0.075 m
3
(2.65 ft
3
)
55 kg (121 lbs)
Bucket 600 mm (24 in)
0.091 m
3
(3.21 ft
3
)
63 kg (139 lbs)
Bucket
700 mm (28 in)
0.107 m
3
(3.78 ft
3
)
71 kg (157 lbs)
Ditch cleaning bucket 850 mm (33 in)
0.069 m
3
(2.44 ft
3
)
66 kg (146 lbs)
Ditch cleaning bucket 1000 mm (39 in)
0.082 m
3
(2.90 ft
3
)
66 kg (146 lbs)
Ditch cleaning bucket 1200 mm (47 in)
0.098 m
3
(3.46 ft
3
)
75 kg (165 lbs)
Offset bucket 850 mm (33 in)
0.073 m
3
(2.58 ft
3
)
92 kg (203 lbs)
Offset bucket 1000 mm (39 in)
0.087 m
3
(3.07 ft
3
)
94 kg (207 lbs)
