Introduction
Symbols
The following symbols are displayed on the machine to provide pictorial information to the
operator. The information and explanations are provided to avoid misinterpretation by the
operator. The symbols have been chosen to provide important information to those
involved with operating, adjusting, maintaining, and repairing this machine.
Description
Locates the lifting points for hoisting the excavator with lifting devices (slings, chains, or
cables).
Location
On either side of the stabilizer blade, and on either side of the boom.
Description
Tie-down points.
Tie-down points during transport to prevent movement during transport.
Location
On either side of the stabilizer blade, and on either side of the undercarriage.
Description
Noise levels produced by the machine.
L
WA
= sound power level
Location
On the upper carriage next to the swiveling console.
Up to serial no. AG02452 for 2503 and 3503
2503: from serial no. AG02453
3503: from serial no. AG02453
Fig. 31: Lifting eyes
Fig. 32: Tie-down points
Fig. 33: Noise level indication
Fig. 34: Noise level indication
Fig. 35: Noise level indication
