OM 25-3503 us – Edition 4.1 * 2503_3503b610.fm 6-17
Technical datac
6.16 Lift capacity table 3503 VDS
All table indications in kg and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The compact excavator’s lift capacity is restricted by the settings of the pressure limiting
valves and the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
A
4.5 m
(14'-8")
3.5 m
(11'-5")
2.5 m
(8'-2")
1.5 m
(4´9“)
B
3.0 m
(9'-8")
800*
(1,764*)
650
(1,433)
750*
(1,653*)
550*
(1,213*)
2.0 m
(6'-6")
845*
(1,863*)
350
(772)
900*
(1,984*)
530
(1,168)
1210*
(2,668*)
890
(1,962)
1.0 m
(3'-3")
900*
(1,984*)
340
(750)
900*
(1,984*)
340
(750)
1125*
(2,480*)
500
(1,102)
1850*
(4,079*)
800
(1,764)
0.0 m
(0'-0")
955*
(2,105*)
340
(750)
955*
(2,105*)
340
(750)
1300*
(2,866*)
460
(1,014)
2150*
(4,740*)
750
(1,653)
î1.0 m
(î3'-3")
1050*
(2,315*)
395
(871)
1300*
(2,866*)
450
(992)
2080*
(4,586*)
750
(1,653)
4200*
(9,259*)
1855
(4,090)
î2.0 m
(
î6'-6")
1150*
(2,536*)
575
(1,268)
1650*
(3,638*)
790
(1,742)
3150*
(6,945*)
1910
(4,211)
Fig. 311: Lift capacity table (model 3503 VDS)
max Permissible load on extended stick
A Reach from live ring center
B Load hook height
* Lift capacity limited by hydraulic system
With the stabilizer blade in travel direction
Without the stabilizer blade, 90° to travel direction
