Wacker Neuson 2503 User Manual

3-16 OM 25-3503 us – Edition 4.1 * * 2503_3503b320.fm
Operation
Meaning of displays and symbols 3503 Tier IV
20
--- Automatic engine speed setting switch (option) 3-12
21
--- Regeneration push button 3-112
22
--- 2nd speed range switch 3-29
23
--- Hydraulic quickhitch (option) switch 3-92
24
--- Wiper/wash system switch 3-49
25
--- Ventilation/heating switch 3-48
26
--- Working light switch 3-36
27
--- Rotating beacon (option) switch 3-37
28
--- Safe load indicator switch (option) 3-102
No. Symbol Color Designation See
Symbol Designation Page
Speed range 1
3-29
Speed range 2
Hour meter
3-18
Operating hours to next maintenance
Time
3-18
Engine speed
Fuel tank capacity 3-18
Coolant temperature 3-13
Engine error
4-6
Machine error
Engine data 4-6
450.2
49.8
12:10
800 rpm
3
4
1
2
1
4
100°
80°
60°
!
