10 Problem Solving
206 Xerox 6204 Wide Format Solution
Problem Solving
10
Paper Jams in Fuser Unit
The following describes how to clear paper jams that occur in the fuser unit.
1 Lift up the upper unit releasing lever to open the
upper unit.
WARNING: Never touch a labeled area on hot or sharp parts. You can get burned or injured.
2 Remove the jammed paper through the opening.
• Gently remove the paper, taking care not to
tear it.
• If the paper is torn, make sure to remove all
torn paper from the machine.
3 When the jammed paper is not visible from the
opening, open the manual feed tray and the
fuser cover.
Upper Unit Releasing Lever
2
1
To Next Page
