11 Appendix
210 Xerox 6204 Wide Format Solution
Appendix
11
Space Requirements
The Xerox 6204 Wide Format Solution with FreeFlow Access Print Server occupies a
minimum of 52.6 square feet (4.89m
2
) of floor space, and requires a minimum of 18
inches (457mm) clearance from its rear vents to the wall. The required clearance from
the floor to the nearest overhead obstruction within the floor space area is
84"
(2135mm).
Note: An additional 14.9 inches (378mm) of clearance is required at the rear of the machine if the
optional document catch tray is installed.
The diagram below illustrates the minimum clearances required for normal operation,
consumables replacement, and maintenance. Your Xerox representative will provide
the support that is necessary to install the machine correctly.
Rear
Front
