16-12 IM 760401-01E
16.8 GP-IB Interface (standard on -C1, /C1 option)
Item Specifications
Electrical and mechanical Conforms to IEEE St’d 488-1978 (JIS C 1901-1987).
specifications
Functional specifications SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT1, C0
Protocol Conforms to IEEE St’d 488.2-1992
(Provides communication commands other than those of the IEEE St’d 488.2 protocol.)
Code ISO (ASCII) code
Address 0 to 30
Clear remote mode Remote mode can be cleared by pressing LOCAL (except during Local Lockout).
16.9 Serial (RS-232-C) Interface (Standard on -C2, /
C2 Option)
Item Specifications
Connector type D-Sub 25-pin (plug)
Electrical specifications Conforms to EIA-232 (RS-232)
Connection Point-to-point
Transmission mode Full-duplex
Synchronization Start-stop synchronization
Baud rate Select from 1200, 2400, 4800, and 9600 bps.
