16-13
IM 760401-01E
Specifications
16
16.10 General Specifications
Item Specifications
Warm-up time Approx. 30 minutes
Operating conditions Temperature: 5 to 40°C
Humidity: 20 to 80% RH (no condensation)
Operating altitude 2000 m or less
Storage conditions Temperature: 25 to 60°C
Humidity: 20 to 80% RH (no condensation)
Rated supply voltage 100 to 120 VAC, 200 to 240 VAC
Permitted supply voltage 90 to 132 VAC, 180 to 264 VAC
range
Rated supply voltage 50/60 Hz
frequency
Permitted supply voltage 48 to 63 Hz
frequency range
Maximum power WT210: 35 VA, WT230: 55 VA
consumption
Insulation resistance 50 MΩ or more at 500 VDC
Between all voltage input terminals and case
Between all current input terminals and output terminals collectively,
Between all voltage input terminals and all current input terminals,
Between all voltage input terminals of input elements,
Between all current input terminals of input elements,
Between all voltage input terminals and power supply plug,
Between all current input terminals and power supply plug,
Between case and power supply plug
Withstand voltage 3700 VAC at 50/60 Hz for one minute
Between all voltage input terminals and case
Between current input terminals collectively and output terminals collectively,
Between all voltage input terminals and all current input terminals,
Between all voltage input terminals of input elements,
Between all current input terminals of input elements,
Between all voltage input terminals and power supply plug,
Between all current input terminals and power supply plug
1500 VAC at 50/60 Hz for one minute
Between case and power supply plug
Oscillation condition Sweep test: Sweeps a frequency range of 8 to 150 Hz, 3 directions each, 1 minute reciprocation
Endurance test: frequency 16.7 Hz, peak-to-peak amplitude 4 mm, 3 directions each, 2 hours.
Shock condition Shock test: Acceleration 490 m/s
2
, 3 directions each
Endurance test: Free fall test Height 100 mm, once on four sides
External dimensions WT210: Approx. 213 (W) × 88 (H) × 379 (D) mm
(excluding projections.) WT230: Approx. 213 (W) × 132 (H) × 379 (D) mm
Weight WT210: Approx. 3 kg
WT230: Approx. 5 kg
Battery backup Backs up the setup parameters and stored data with the lithium battery.
Standard accessories • Power cord: 1 piece
• Spare power fuse : 1 piece (Attached to the fuse holder)
• 24-pin connector: 1 piece (included in products with the /DA4, /DA12, and /CMP options)
• Current input protection cover: 1 piece (included with the WT210/WT230)
• Hind feet rubber: 1 set
• User’s manual : 1 piece (this manual)
To Next Page
