JOHNSON CONTROLS
130
SECTION 8 - MICROPANEL
Form 201.47-ICOM1
Issue date: 17/11/2022
History key
LD10605
History key
History key operation
The HISTORY key provides the user access to many
unit and system operating parameters captured at the
instant a unit or system safety (fault) shutdown occurs.
The history buffer will also capture system data at the
time of normal shutdowns such as cycling shutdowns.
When the HISTORY key is pressed the following
screen is displayed:
HISTORY CHOOSE HISTORY TYPE
◄ ► XXXXXXXXXXXXXXXXXXXXXXXXXXXX
The ◄ and ► (ARROW) keys allow choosing be-
tween NORMAL SHUTDOWNS and FAULT SHUT-
DOWNS. Fault shutdowns provide information on
safety shutdowns, while normal shutdowns provide
chiller cycling information on temperature (demand),
cycling, remote, system switch, and so on, shutdowns
that are non-safety related shutdowns. Once the selec-
tion is made, the (ENTER) key must be pressed to
enter the selection.
Normal shutdowns history
If the NORMAL SHUTDOWNS history is selected,
the following screen is displayed:
NORM HIST XX 18-JUN-2004 10:34:58 AM
YYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYY
XX is the normal shutdown number. The display pro-
vides date and time of the shutdown and the reason for
the cycling shutdown (YYY….).
The operator can view any of the stored 20 single dis-
play normal shutdown history buffers. History buffer
number 1 provides the most recent shutdown informa-
tion and buffer number 20 is the oldest safety shutdown
information saved. The ◄ and ► (ARROW) keys allow
scrolling between each of the history buffers. The ►
(ARROW) key scrolls to the next normal history shut-
down and the ◄ (ARROW) key scrolls to the previous
normal history shutdown.
The following display is displayed on a normal shut-
down due to shutdown on lack of cooling demand.
NORM HIST XX 18-JUN-2004 10:34:58 AM
SYS X COOLING DEMAND SHUTDOWN
Fault shutdowns history
If the FAULT SHUTDOWNS history is selected, the
following screen is displayed:
FAULT HIST XX 18-JUN-2004 10:34:58 AM
YYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYY
Figure 55 - History key
