Date/time and schedule keys
LD10605
Date and time key
Schedule key
Date/time key operation
When the DATE/TIME key is pressed, the chiller mi-
croprocessor will display the date and the time. This
feature is useful and required for using the Daily
Schedule. It is also a valuable tool for troubleshooting
to allow a technician to determine the time of the fault,
which is stored in the history memory buffers. When
the DATE/TIME key is pressed, the following first dis-
play screen will be displayed:
CLOCK FRI 18-JUN-2011 10:15:33 AM
DAY OF WEEK ◄ ► = XXX
Whenever any changes are made, the (ENTER) key
must be pressed to store the data.
ARROW) key scrolls to the next item that can be pro-
previous item.
The day of the week is the first display and can be
RIGHT ARROW) key to select the day. After the day is
selected, the (ENTER) key must be pressed to store
the data.
CLOCK FRI 18-JUN-2011 10:15:33 AM
DAY OF MONTH = XX
the day of the month:
CLOCK FRI 18-JUN-2011 10:15:33 AM
DAY OF MONTH = XX
The day of the month can be selected by keying in the
numerical value to select the day. After the day of the
month is selected, the (ENTER) key must be pressed
to store the data.
A “0” must be typed in to select dates for
days of the 1st through the 9th.
to month:
CLOCK FRI 18-JUN-2011 10:15:33 AM
MONTH ◄ ► = XXX
Figure 59 - Date/time and schedule key
