SECTION 9 - MAINTENANCE
Form 201.47-ICOM1
Issue date: 17/11/2022
Table 38 - Pressure transducer output voltage, measured signal to return at the transducer
Suction pressure transducer
(125 psig)
Condenser liquid, discharge, and economizer pressure
transducers
Pressure Voltage Pressure Voltage
0 0.50 0 0.50
5 0.66 25 0.75
10 0.82 50 1.00
15 0.98 75 1.25
20 1.14 100 1.50
25 1.30 125 1.75
30 1.46 150 2.00
35 1.62 175 2.25
40 1.78 200 2.50
45 1.94 225 2.75
50 2.10 250 3.00
55 2.26 275 3.25
60 2.42 300 3.50
65 2.58 325 3.75
70 2.74 350 4.00
75 2.90 375 4.25
80 3.06 400 4.50
85 3.22
90 3.38
95 3.54
100 3.70
105 3.86
110 4.02
115 4.18
120 4.34
125 4.50
