SECTION 8 - MICROPANEL
JOHNSON CONTROLS
149
Form 201.47-ICOM1
Issue date: 17/11/2022
8
Options key
LD10605
Options key
Options key operation
The OPTIONS key provides the user with a display of
unit configuration and the capability to modify the con-
figuration. These options can only be viewed under the
OPTIONS key. To view the current options settings,
press the OPTIONS key. Each press of the OPTIONS
ARROW) keys will scroll
ARROW)
keys allow changing the option choices. The (EN-
TER) key must be pressed after a selection is made to
save the change in memory.
An explanation of each option message is provided.
Display language selection
The display language can be selected for English, Ital-
ian, Polish, Hungarian, German, French, Portuguese,
and Spanish.
OPTIONS DISPLAY LANGUAGE
◄ ► XXXXXXXXXXXXXXXXXX
The default language is English.
Local/remote control mode selection
Local or Remote Control Mode allows the user to se-
lect the chilled liquid temperature control mode.
OPTIONS LOCAL / REMOTE CONTROL MODE
◄ ► XXXXXXXXXXXXXXXXXX
When LOCAL CONTROL mode is selected, chilled
liquid control is from the keypad of the chiller. In local
mode, a remote device can read system data, but not
reset operating parameters.
OPTIONS LOCAL / REMOTE CONTROL MODE
◄ ► LOCAL CONTROL
When REMOTE CONTROL mode is selected, control
of the chilled liquid setpoint is from a remote device
such as an BAS controller.
OPTIONS LOCAL / REMOTE CONTROL MODE
◄ ► REMOTE CONTROL
The default mode is LOCAL CONTROL.
Figure 58 - Options key
