JOHNSON CONTROLS
142
SECTION 8 - MICROPANEL
Form 201.47-ICOM1
Issue date: 17/11/2022
Unit Setup Mode
Use the unit setup mode to modify all of the program-
mable values that the user does not usually ever change.
These are either programmed at the factory or by ser-
vice personnel on the job. You can enter this mode by
pressing the PROGRAM key, entering the password
4245, and pressing ENTER.
After successful entry of the password, a 5 minute
timer is initiated. When this timer expires, Unit Setup
Mode is exited and the screen reverts to the Status key
display.
The following table lists the values that can be pro-
grammed in this mode.
Unit setup mode
setting
Mode to change Minimum Maximum Default
Sys 1 Number of Cond
Fans
Any 4 14 6
Sys 2 Number of Cond
Fans
Any 4 14 6
Compressor 1
Operating Hours
Any 0 99,999 0
Compressor 2
Operating Hours
Any 0 99,999 0
Compressor 1 Starts Any 0 99,999 0
Compressor 2 Starts Any 0 99,999 0
Clear History Bu󰀨ers Any No / Yes No
Remote Temp Reset
Option
Any Disabled / Enabled Disabled
Remote Current Limit
Option
Any Disabled / Enabled Disabled
Sound Limit Option Any Disabled / Enabled Disabled
Remote Inputs Service
Time
Quick Start Disabled
Quick Start Enabled
300 s
15 s
3600 s
3600 s
900 s
900 s
Condenser Fan
Control
Free Cooling
Disabled
STD staged,
OPT staged,
OPT VSD,
OPT Enhanced fans
OPT VSD
Sys 1 Compressor
Displacement
Any CTS24 = 62, CTS36 = 82
CTS45 = 100, CTS51 = 128,
CTS70 = 187, GTS75 = 217
--
Sys 2 Compressor
Displacement
Any Same as Sys 1 --
Maximum Compressor
Speed
Any 121.0 Hz 210.0 Hz 180.0 Hz
Table 26 - Setup mode programmable values
