ABB ACS355 series User Manual

104 Control panels
How to view information about the backup
Step Action Display
1. Go to the Main menu by pressing if you are in the
Output mode, otherwise by pressing repeatedly until
you get to the Main menu.
2. Go to the Par backup mode by selecting PAR BACKUP
on the menu with keys and , and pressing
.
3. Select BACKUP INFO on the Par backup menu with keys
and , and press . The display shows the
following information about the drive where the backup
was made:
DRIVE TYPE: type of the drive
DRIVE RATING: rating of the drive in format XXXYZ,
where
XXX: Nominal current rating. If
present, an “A” indicates a decimal
point, eg, 9A7 means 9.7 A.
Y: 2 = 200 V
4 = 400 V
Z: i = European loading package
n = US loading package
FIRMWARE: firmware version of the drive.
You can scroll the information with keys and .
4. Press to return to the Par backup menu.
MENU
EXIT
PARAMETERS
ASSISTANTS
CHANGED PAR
EXIT ENTER
00:00
LOC
MAIN MENU 1
ENTER
UPLOAD TO PANEL
BACKUP INFO
DOWNLOAD FULL SET
DOWNLOAD APPLICATION
DOWNLOAD USER SET1
EXIT SEL
00:00
LOC
PAR BACKUP 1
SEL
DRIVE TYPE
ACS355
3304 DRIVE RATING
9A74i
3301 FIRMWARE
EXIT
00:00
LOC
BACKUP INFO
ACS355
3304 DRIVE RATING
9A74i
3301 FIRMWARE
241A hex
EXIT
00:00
LOC
BACKUP INFO
EXIT
UPLOAD TO PANEL
BACKUP INFO
DOWNLOAD FULL SET
DOWNLOAD APPLICATION
DOWNLOAD USER SET1
EXIT
SEL00:00
LOC
PAR BACKUP 1
