Fieldbus control with embedded fieldbus 323
 Reference handling
The control of rotation direction is configured for each control location (EXT1 and
EXT2) using the parameters in group 10 START/STOP/DIR. Fieldbus references are
bipolar, ie, they can be negative or positive. The following diagrams illustrate how
group 10 parameters and the sign of the fieldbus reference interact to produce the
reference REF1/REF2.
Direction determined by
the sign of COMM
Direction determined by digital
command, eg, digital input,
control panel
Par. 1003
DIRECTION
= FORWARD
Par. 1003
DIRECTION
= REVERSE
Par. 1003
DIRECTION
= REQUEST
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100% 100%
ref. 1/2
Resultant
REF1/2
163%
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100% 100%
ref. 1/2
Resultant
REF1/2
163%
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100% 100%
ref. 1/2
Resultant
REF1/2
163%
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100% 100%
ref. 1/2
Resultant
REF1/2
163%
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100%
100%
ref. 1/2
Resultant
REF1/2
163%
Fieldbus
-163%
Max. ref.
–[Max. ref.]
-100% 100%
ref. 1/2
Resultant
REF1/2
163%
Direction
command:
FORWARD
Direction
command:
REVERSE

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
