Fieldbus control with fieldbus adapter 341
Setting up communication through a fieldbus adapter
module
Before configuring the drive for the fieldbus control, the adapter module must be
mechanically and electrically installed according to the instructions given in section
Attach the optional fieldbus module on page 38, and the module manual.
The communication between the drive and the fieldbus adapter module is activated
by setting parameter 9802 COMM PROT SEL to EXT FBA. The adapter-specific
parameters in group 51 EXT COMM MODULE must also be set. See the table below.
Parameter Alternative
settings
Setting for
fieldbus
control
Function/Information
COMMUNICATION INITIALIZATION
9802 COMM PROT
SEL
NOT SEL
STD MODBUS
EXT FBA
MODBUS
RS232
EXT FBA Initializes the
communication between the
drive and the fieldbus
adapter module.
ADAPTER MODULE CONFIGURATION
5101 FBA TYPE - - Displays the type of the
fieldbus adapter module.
5102 FB PAR 2 These parameters are adapter module-specific. For more
information, see the module manual. Note that not all of these
parameters are necessarily used.
……
5126 FB PAR 26
5127 FBA PAR
REFRESH
(0) DONE
(1) REFRESH
- Validates any changed
adapter module
configuration parameter
settings.
Note: In adapter module, the parameter group number is A (group 1) for group 51 EXT
COMM MODULE.
TRANSMITTED DATA SELECTION
5401
…
5410
FBA DATA IN 1
…
FBA DATA OUT
10
0
1…6
101…9999
Defines the data transmitted
from the drive to the fieldbus
controller.
5501
…
5510
FBA DATA OUT
1
…
FBA DATA OUT
10
0
1…6
101…9999
Defines the data transmitted
from the fieldbus controller
to the drive.
Note: In adapter module, the parameter group number is C (group 3) for group 54 FBA DATA
IN and B (group 2) for group 55 FBA DATA OUT.
