ABB ACS355 series User Manual

Operation principle and hardware description 31
Type designation key
The type designation contains information on the specifications and configuration of
the drive. You find the type designation on the type designation label attached to the
drive. The first digits from the left express the basic configuration, for example
ACS355-03E-07A3-4. The optional selections are given after that, separated by +
signs, for example +J404. The explanations of the type designation selections are
described below.
ACS355 product series
01 = 1-phase input
03 = 3-phase input
1-phase/3-phase
In format xxAy, where xx indicates the integer part and y the fractional part,
eg, 07A3 means 7.3 A.
For more information, see section Ratings on page 374.
2 = 200…240 V AC
4 = 380…480 V AC
Input voltage range
E = EMC filter connected, 50 Hz frequency
U = EMC filter disconnected, 60 Hz frequency
See section Differences between the default values in E and U type drives.
Configuration
1) The ACS355 is compatible with panels that have the following panel revisions and panel firmware
versions. To find out the revision and firmware version of your panel, see page 76.
Panel type Type code Panel revision Panel firmware version
Basic control panel ACS-CP-C M or later 1.13 or later
Assistant control panel ACS-CP-A F or later 2.04 or later
Assistant control panel (Asia) ACS-CP-D Q or later 2.04 or later
Note that unlike the other panels, the ACS-CP-D is ordered with a separate material code.
Options
ACS355-03E-07A3-4+J404+...
Output current rating
B063 = IP66/IP67/UL Type 4x enclosure
(product variant)
J400 = ACS-CP-A assistant control panel
1)
J404 = ACS-CP-C basic control panel
1)
J402 = MPOT-01 potentiometer
K451 = FDNA-01 DeviceNet
K452 = FLON-01 L
ONWORKS®
K454 = FPBA-01 PROFIBUS DP
K457 = FCAN-01 CANopen
K458 = FMBA-01 Modbus RTU
K466 = FENA-01EtherNet/IP / Modbus
TCP/PROFINET IO
K469 = FECA-01 EtherCAT
K470 = FEPL-02 Ethernet POWERLINK
K473 = FENA-11EtherNet/IP / Modbus
TCP/PROFINET IO
K475 = FENA-21EtherNet/IP / Modbus
TCP/PROFINET IO
H376 = Cable gland kit (IP66/IP67/UL Type 4x)
F278 = Input switch kit
C169 = Pressure compensation valve
Extension modules
G406 = MPOW-01 auxiliary power extension
module
L502 = MTAC-01 pulse encoder interface
module
L511 = MREL-01 output relay module

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
