336 Fieldbus control with embedded fieldbus
8 LIMIT 1 Operation is limited by internal protection limits or
group 20 LIMITS settings (excluding speed and
frequency limits).
0 Operation is within internal protection limits and
according group 20 LIMITS settings (excluding speed
and frequency limits).
9 SUPERVISION 1 A supervised parameter (group 32 SUPERVISION) is
outside its limits.
0 All supervised parameters are within limits.
10 REV_REF 1 Drive reference is in reverse direction.
0 Drive reference is in forward direction.
11 REV_ACT 1 Drive is running in reverse direction.
0 Drive is running in forward direction.
12 PANEL_LOCAL 1 Control is in control panel (or PC tool) local mode.
0 Control is not in control panel local mode.
13 FIELDBUS_LOCAL 1 Control is in fieldbus local mode
0 Control is not in fieldbus local mode.
14 EXT2_ACT 1 Control is in EXT2 mode.
0 Control is in EXT1 mode.
15 FAULT 1 Drive is in a fault state.
0 Drive is not in a fault state.
DCU profile Status word, parameter 0304 FB STS WORD 2
Bit Name Value Status
16 ALARM 1 An alarm is on.
0 No alarms are on.
17 NOTICE 1 A maintenance request is pending.
0 No maintenance request
18 DIRLOCK 1 Direction lock is ON. (Direction change is locked.)
0 Direction lock is OFF.
19 LOCALLOCK 1 Local mode lock is ON. (Local mode is locked.)
0 Local mode lock is OFF.
20 CTL_MODE 1 Drive is in vector control mode.
0 Drive is in scalar control mode.
21 JOGGING ACTIVE 1 Jogging function is active.
0 Jogging function is not active.
DCU profile Status word, parameter 0303 FB STS WORD 1
Bit Name Value Status
