ABB ACS355 series User Manual

Technical data 379
Type
ACS355-
Input
Amps
Frame
size
MMP type E
1,2)
Min. encl. vol.
5)
dm
3
cu in
1-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
01x-02A4-2 6.1 R0 MS132-6.3 & S1-M3-25
3)
18.9 1152
01x-04A7-2 11.0 R1 MS165-16 18.9 1152
01x-06A7-2 16.0 R1 MS165-20 18.9 1152
01x-07A5-2 17.0 R2 MS165-20 - -
01x-09A8-2 21.0 R2 MS165-25 - -
3-phase U
N
= 200…240 V (200, 208, 220, 230, 240 V)
4)
03x-02A4-2 4.3 R0 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-03A5-2 6.1 R0 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-04A7-2 7.6 R1 MS132-10 & S1-M3-25
3)
18.9 1152
03x-06A7-2 11.8 R1 MS165-16 18.9 1152
03x-07A5-2 12.0 R1 MS165-16 18.9 1152
03x-09A8-2 14.3 R2 MS165-16 - -
03x-13A3-2 22.0 R2 MS165-25 - -
03x-17A6-2 25.0 R2 MS165-32 - -
03x-24A4-2 41.0 R3 MS165-54 - -
03x-31A0-2 50.0 R4 MS165-65 - -
03x-46A2-2 69.0 R4 MS5100-100 - -
3-phase U
N
= 380, 400, 415 V
4)
03x-01A2-4 2.2 R0 MS132-2.5 & S1-M3-25
3)
18.9 1152
03x-01A9-4 3.6 R0 MS132-4.0 & S1-M3-25
3)
18.9 1152
03x-02A4-4 4.1 R1 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-03A3-4 6.0 R1 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-04A1-4 6.9 R1 MS132-10 & S1-M3-25
3)
18.9 1152
03x-05A6-4 9.6 R1 MS132-10 & S1-M3-25
3)
18.9 1152
03x-07A3-4 12.0 R1 MS165-16 18.9 1152
03x-08A8-4 14.0 R1 MS165-16 18.9 1152
03x-12A5-4 19.0 R3 MS165-20 - -
03x-15A6-4 22.0 R3 MS165-25 - -
03x-23A1-4 31.0 R3 MS165-32 - -
03x-31A0-4 52.0 R4 MS165-65 - -
03x-38A0-4 61.0 R4 MS165-65 - -
03x-44A0-4 67.0 R4 MS5100-100 - -
3-phase U
N
= 440, 460, 480 V
4)
03x-01A2-4 1.8 R0 MS132-2.5 & S1-M3-25
3)
18.9 1152
03x-01A9-4 3.0 R0 MS132-4.0 & S1-M3-25
3)
18.9 1152
03x-02A4-4 3.4 R1 MS132-4.0 & S1-M3-25
3)
18.9 1152
03x-03A3-4 5.0 R1 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-04A1-4 5.8 R1 MS132-6.3 & S1-M3-25
3)
18.9 1152
03x-05A6-4 8.0 R1 MS132-10 & S1-M3-25
3)
18.9 1152

ABB ACS355 series Specifications

General

Power Range	0.37 to 22 kW
Protection Class	IP20
Output Frequency	0 to 500 Hz
Braking Chopper	Built-in
Control Method	Scalar control, Vector control
Ambient Temperature	-10 to +50 °C
Communication Protocols	Modbus, CANopen
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Cooling Method	Air-cooled
Number of Phases	3-phase
