42/24-10 EN Rev. 9 Chapter 7: Gas Analyzer Configuration 7-C-9
Removing a System Module
Sequence when
Removing System
Modules
When removing system modules from the gas analyzer proceed according to the
following sequence:
1. Remove the system module in the software (see below for instructions)
2. Dismount the system module from the gas analyzer.
Step Action
1 Select the Set Up System Modules menu item.
The list of the system modules existing in the system is displayed.
2 Select the system module to be removed (and not replaced).
Press the DELETE softkey. 3
This will irretrievably remove the system module’s parameter
settings and function block configuration!
4 In the list the deleted system module’s status will change to Deleted.
Removing an Installed
System Module
without a Replacement
5 Save the configuration change by pressing ENTER or discard it by
pressing Back.
To Next Page
