1-8 Chapter 1: Preparing the Installation 42/24-10 EN Rev. 9
Power Supply
Application The central unit power supply provides 24 VDC for the electronics module and
one analyzer module built-in in the central unit or one external analyzer module.
Input Voltage 100–240 VAC, –15 %, +10 %
Input Current max. 2.2 A
Line Frequency Range 50–60 Hz ± 3 Hz
Power Consumption max. 187 W
Output Voltage 24 VDC ± 5 %
Power Supply
Specifications
Line Power Connection 3-pin grounded-instrument connector
per EN 60320/ C14
Module Power Consumption
System Controller approx. 15 W
I/O Modules approx. 10 W per module
Caldos25 max. 25 W
Caldos27 max. 12 W
Limas11 max. 85 W
Magnos206 max. 50 W
Magnos27 max. 35 W
MultiFID14 max. 65 W
Uras26 max. 95 W
Module
Power Consumption
Gas Module approx. 20 W
