7-D-8 Chapter 7: Gas Analyzer Configuration 42/24-10 EN Rev. 9
Moving a Display Element Within a Page
Step Action
1 Select menu item Display.
2 Select the display element in the display overview.
3 Select the parameter Position.
The nine possible positions are graphically represented.
If the display element is on a:
system page, its position can only be exchanged with that of another
display element (the softkey Swap Display is
pressed.)
user page, Its position can either be exchanged with that of
another display element (the softkey Swap Display
is pressed), or it can be moved to a free position (the
softkey Swap Display is not pressed).
4
Select the desired position with the corresponding number key.
Moving a Display
Element Within a Page
5 Switch to measuring.
The display element is now displayed at the new position.
