296 Installation
Unpacking
If you have ordered the FSO module option separately, it is delivered in its own
package. The package contains:
• the FSO module (1)
• connector plugs and attachment screws (2)
• 2 × FSO data cable, 220 mm and 85 mm (3)
• 2 × STO cable, 220 mm and 400 mm (4)
• connector for the power supply wires (5)
• mounting plate for ZCU-14 (6). The default mounting plate for ZCU-12 is attached
to the module.
• user's manual (not shown in the figure).
Examining the delivery
Make sure that all parts are in the package and that there are no signs of damage.
Notify the shipper immediately if you find damaged parts. Do not use damaged parts,
they must be replaced.
Make sure that the FSO module is of the correct type. Refer to Type designation label
on page 39.
