1.2.2 Safety symbols on manipulator labels
Introduction to symbols
This section describes safety symbols used on labels (stickers) on the manipulator.
Symbols are used in combinations on the labels, describing each specific warning.
The descriptions in this section are generic, the labels can contain additional
information such as values.
Note
The symbols on the labels on the product must be observed. Additional symbols
added by the integrator must also be observed.
Types of symbols
Both the manipulator and the controller are marked with symbols, containing
important information about the product. This is important for all personnel handling
the robot, for example during installation, service, or operation.
The safety labels are language independent, they only use graphics. See Symbols
on safety labels on page 19.
The information labels can contain information in text.
Symbols on safety labels
DescriptionSymbol
Warning!
xx0900000812
Warns that an accident may occur if the instructions are not
followed that can lead to serious injury, possibly fatal, and/or
great damage to the product. It applies to warnings that apply
to danger with, for example, contact with high voltage electrical
units, explosion or fire risk, risk of poisonous gases, risk of
crushing, impact, fall from height, etc.
Caution!
xx0900000811
Warns that an accident may occur if the instructions are not
followed that can result in injury and/or damage to the product.
It also applies to warnings of risks that include burns, eye injury,
skin injury, hearing damage, crushing or slipping, tripping, im-
pact, fall from height, etc. Furthermore, it applies to warnings
that include function requirements when fitting and removing
equipment where there is a risk of damaging the product or
causing a breakdown.
Prohibition
xx0900000839
Used in combinations with other symbols.
Continues on next page
Product manual - IRB 1010 19
3HAC081964-001 Revision: B
© Copyright 2022 ABB. All rights reserved.
