9.7 Special tools
General
All service instructions contain lists of tools required to perform the specified
activity. The required tools are a sum of standard tools, defined in the section
Standard toolkit on page 324, and of special tools, listed directly in the instructions
and also gathered in this section.
Special tools
Note
If the replacing procedure is not listed in the table below, only standard tools are
needed for the procedure.
Tools and equipment with spare part number:
(These tools can be ordered from ABB)
24 VDC power supply-
Calibration tool box, Axis Calibration3HAC074119-001
Delivered as a set of calibration tools.
Required if Axis Calibration is the valid calibration
method for the robot.
Sonic tension meter-
Used for measuring the timing belt tension.
Dynamometer-
Used for measuring the timing belt tension.
Axis-2 radial sealing assembly tool3HAC082535-001
Axis-4 radial sealing assembly tool3HAC082535-003
Radial sealing pressfit tool3HAC082535-002
Special toolkit3HAC071022-001
Includes M12 connector assembly tool and Brake release
button assembly tool.
Product manual - IRB 1010 325
3HAC081964-001 Revision: B
© Copyright 2022 ABB. All rights reserved.
9 Reference information
9.7 Special tools
