Configure ControlLogix Analog I/O Modules Chapter 7
Configuration Tab
The fields on the Configuration tab are specific to the module type. The
following are examples of tasks you complete via this tab:
• Select an input or output type.
• Select a module’s operating range.
• Define scaling parameters.
1756-IF8I Module
For information on this tab’s configurable parameters, see Chapter 3, 1756-IF8I
Isolated Analog Input Module on page 41.
