Rockwell Automation Publication 1756-UM540E-EN-P - December 2017 89
Chapter 5
1756-OF8I Isolated Analog Output Module
The 1756-OF8I module has eight isolated channels. Each channel supports the
following output types:
• Current
• Vo l t ag e
The module provides 16-bit resolution. Additional features are described in
this chapter.
1756-OF8I Module Features
The 1756-OF8I module has the following features:
• Multiple Output Ranges
• Channel Offset
• Ramping/Rate Limiting
• Hold for Initialization
• Clamping/Limiting
• Clamp/Limit Alarms
• Data Echo
• Redundant Owners
Topic Page
1756-OF8I Module Features 93
1756-OF8I Diagrams 93
Drive Different Loads with the 1756-OF8I Module 96
Fault and Status Reporting 97
Redundant Owners 98
IMPORTANT
Most of the features available on the 1756-OF8I module are software
configurable. For more information on how to configure the module, see
Chapter 7, Configure ControlLogix Analo
g I/O Modules on page 125.
