Chapter 5 1756-OF8I Isolated Analog Output Module
Figure 30 - 1756-OF8I Module Wiring Diagram - Voltage Output Type
Drive Different Loads with
the 1756-OF8I Module
When the 1756-OF8I module operates with a Current output load, each channel
automatically adjusts its output power for 0…1000 ohm loads. The module’s 24V
backplane current requirements vary based on load.
For more information the module’s 24V current requirements, see the 1756
ControlLogix® I/O Specifications Technical Data, publication 1756-TD002
.
1
3
5
7
019
1112
4131
6151
8171
0291
2212
4232
6252
8272
0392
2313
33
6353
2
34
8
6
4
+
–
OUT_0/V
OUT_0/I
RTN_0
Not used
OUT_2/V
OUT_2/I
RTN_2
Not used
>1000  User
Analog Output
Device
OUT_4/V
OUT_4/I
RTN_4
Not used
OUT_6/V
OUT_6/I
RTN_6
Not used
Not used
Not used
OUT_1/V
OUT_1/I
RTN_1
Not used
OUT_3/V
OUT_3/I
RTN_3
Not used
OUT_5/V
OUT_5/I
RTN_5
Not used
OUT_7/V
OUT_7/I
RTN_7
Not used
Not used
Not used
IMPORTANT: Remember the following:
• If separate power sources are used, do
not exceed the specific isolation
voltage. For more information on
module specifications, see the 1756
ControlLogix I/O Specifications
Technical Data, publication
1756-TD002
.
• Place additional devices anywhere in
the loop.
