Appendix A
Analog I/O Module Tag Definitions
Module tags are created when you add a module to the Studio 5000 Logix
Designer® application project. The set of tags that are associated with any module
depends on the module type and the connection type. There are three sets of tags
for each module:
• Configuration
• Input
• Output
Access the Tags
You can view tags from the Tag Editor. Complete the following steps.
1. Open your Logix Designer application project.
2. Right-click Controller Tags and choose Monitor Tags.
Topic Page
Access the Tags 181
1756-IF8I Module Tags 183
1756-IRT8I Module Tags 189
1756-IR12 Module Tags 196
1756-IT16 Module Tags 200
1756-OF8I Module Tags 204
Redundant Owner Configuration Tags 211
Array Data Structures 212
