69
www.amcelettronica.com
KX series v.1.70
ADEMCO MENU
The control unit is set to send digital protocols ademco 4+2 and CONTACT ID. The system can be freely configured for each input
zone and each type of event. You can have up to 8 telephone numbers with 8 different system IDs that can send data to various
reception control units. It is possible to send contact ID data via PSTN, GSM, GPRS,LAN.
With this parameter you can display and change all of the codes related to all of the events available in the control unit.
SIREN
320
ZONE TAMPER
137
NO 220V
301
LOW BATTERY
309
NO GSM LINE
351
SYSTEM ON/OFF
401
REMOTE ON/OFF
407
ON/OFF BY TIMER
403
LIFE TEST
602
RF NOISE
344
WIR.DEV.LOW BAT.
384
WIREL.NO SUPER.
381
WIRELESS TAMPER
383
PERIPH.TAMPER
341
PROG.MODE ENTRY
627
SYSTEM RESTART
305
WRONG CODE
461
ZONES EXCLUSION
570
COERCION
121
ZONE PANIC
120
TECNO INPUT
150
EVENT LOG RESET
621
GENERAL RESET
313
PHONE LINE
352
[01] zone 1
130
[64] zone 64
130
MASKING
138
CONNECT FAILURE
143
INPUT FAILURE
144
AMRMING FAILED
453
In the figure, the list of events that can be transmitted in CID, the event code number including the brackets and the standard ones
used by the protocol. It is freely changed all of the event codes for any zone input and any type of event available. Select the desired
event and confirm with SEND . The number flashes and so can be changed.
It is possible enable or disable the single events of sending.
event disabled
event enabled
For enabled/disabled events, press ENTER in the single event and modify by pressing CANCEL
TEL.number [01]
00033445856456
PREFIX TEL [01]
Pstn ( ) GSM ( )
Set the number fo CMS, select the prefix where is requested, and select the type of message that will be sent.
This is the amount of the time the system waits for a response during a call before going on to the next one. It can be set from 1
to 50 seconds.
enconding TEL [01]
Contact ID
