CHAPTER 4: CONFIGURATION
JAVA TOOL
Select the respective user in the working area of the User menu for the favorite list and open the Favorites tab.
FIGURE 4-26. DEFINITION—USER
To create a favorite list for any user, proceed as follows:
1. Select the CPUs in the CPU available list that should be added to the favorite list (CPU assigned). By pressing the <Ctrl>
at the same time, more than one CPU Device can be marked.
2. Press the > button to move the marked CPU Devices to the favorite list. If you press the >> button, the first eight CPU Devices
from the CPU available list will be moved to the favorite list (CPU assigned).
3. The order of marked CPU Devices within the favorite list can be changed by pressing <+> and <->.
4. To remove marked CPU Devices from the favorite list, press the < button. If you press the << button, all CPU Devices
will be removed from the favorite list.
4.5.3 USER MACROS
In this menu, macro commands for switching, disconnection or user administration can be created. Macro commands are created
for each user separately.
A macro can execute up to 16 switching commands successively.
The execution of the macros is done via hotkey and the <F1>-<F16> function keys (see Section 5.1.3).
To execute user macros, the user has to be logged in to the matrix.
