CHAPTER 2: OVERVIEW
NOTE: Functions, colors and symbols used in the Grid Port View are identical to those in the port status of the Matrix View.
2.7.4 EXTENDER OSD
All extenders used with the Modular KVM Matrix Switch are provided with their own OSD to display the connection status
of the console.
FIGURE 2-16. EXTENDER OSD
