CHAPTER 5: OPERATION
5.5 CON SWITCH
KVM extender CON Units connected to a local source (computer, CPU) can be locally switched via the matrix. Switching is
performed between the local source and the KVM connection and can be executed via hotkeys or via OSD.
If you switch to the local source, the KVM connection will be automatically disconnected.
NOTE: When using CON Units with the possibility to connect a local source (computer, CPU) in a Multi-Screen Control environment,
the local switching will be disabled.
You have the following option to switch to the local source.
OSD
OSD
 Select Switch in the main menu.
FIGURE 5-7. CON SWITCH
To switch to a local source, proceed as follows:
1. If you are not in the Switch menu of the OSD, start Command Mode with the hotkey (see Section 4.1).
2. Press <o> to open OSD. You will see a list of all available CPUs as a start menu.
3. Switch to the CPU in the Local CPU list. The switching operation to the local source will be performed immediately.
