CHAPTER 5: OPERATION
You can select the following switching operations.
TABLE 5-6. SWITCHING OPERATIONS
KEYBOARD COMMAND FUNCTION
<current hotkey>, <Num 0> Switching of the USB-HID signal to the display (CON Unit with keyboard and mouse)
<current hotkey>, <Num 1> Switching of the USB-HID signals to display #1
<current hotkey>, <Num 2> Switching of the USB-HID signals to display #2
<current hotkey>, <Num 3> Switching of the USB-HID signals to display #3
<current hotkey>, <Num 4> Switching of the USB-HID signals to display #4
5.7 USB 2.0 SWITCHING
Switching USB 2.0 extenders basically works like switching KVM extenders. The following scenarios to switch USB 2.0 extenders
are possible.
1. An extender unit with USB 2.0 will be created and assigned to an already existing device with existing KVM extender units
(see Section 4.10 or Section 4.11.1).
2. A separate device for the extender unit with USB 2.0 will be created without assigning a KVM extender unit to that device.
This possibility offers separate switching of the USB 2.0 signal (see Section 4.10 or Section 4.11.1).
NOTE: Switching USB 2.0 signals uses Extended Switching functionality (see Section 5.3).
When using parallel operation within the matrix, set the Release Time in the Configuration > Switch menu to 10 seconds or more
(see Section 4.11.6). Otherwise, the connection of the USB 2.0 extender will not be established for security and stability reasons.
5.8 PRESETS
Predefined macros to switch the matrix without loading a new configuration can be created and activated in this menu.
You have the following option to access the menu.
