CHAPTER 4: CONFIGURATION
The selection boxes in the Virtual Console column contain a filter function for easy selection of a single CON from a larger pool
of CON devices (see Chapter 4.2.2).
4.4 SYSTEM SETTINGS
You have the option to configure the system settings of the Modular KVM Matrix Switch.
 The configuration of the system settings can only be done by users with administrator rights.
4.4.1 SYSTEM DATA
The system configuration is set in this menu.
You have the following options to access the menu.
OSD
You can select the following settings.
TABLE 4-11. SYSTEM DATA SETTINGS
FIELD SELECTION DESCRIPTION
Device Text
Enter the device name of the matrix
(default: SWITCH_01)
Name Text
Enter the name of the configuration that is used to save the current settings
(default: Standard)
Info Text
Additional text field to describe the configuration
(default: Factory settings)
Sub Matrix
activated
If the matrix is defined as a sub matrix in the OSD, the user will lose control. Control
can be recovered by using the keyboard command <Shift>, <Shift>, <s>, <o>. The OSD
for the matrix that has been defined as a sub matrix will be reopened.
deactivated Function not active (default)
Load Default
activated Starting the matrix after a restart or a switch-on with the default configuration
deactivated
Starting the matrix after a restart or a switch-on with the last saved configuration
(default).
Auto Save
activated
Save the current configuration of the matrix in the flash memory periodically.
NOTE: During the save operation, the matrix will not operate. Saving takes place every
600 seconds, as long as changes of the configuration or switching operations have
been executed in the meantime.
deactivated Function not active (default)
