CHAPTER 2: OVERVIEW
2.4 PRODUCT RANGE
TABLE 2-3. PRODUCT RANGE
PART NUMBER DESCRIPTION
ACX576, ACX576S Modular KVM Matrix Switch with 576 ports, unpopulated
ACX288 Modular KVM Matrix Switch with 288 ports, unpopulated
ACX160 Modular KVM Matrix Switch with 160 ports, unpopulated
ACX080 Modular KVM Matrix Switch with 80 ports, unpopulated
ACX048 Modular KVM Matrix Switch with 48 ports, unpopulated
2.5 OPTIONS
TABLE 2-4. OPTIONS
PART NUMBER DESCRIPTION
ACXIO8-C CATx I/O board
ACXIO8-SM Fiber I/O board, single-mode
ACXIO8-HS Fiber I/O board, single-mode, 3.125 Gbit/s
ACXIO8-6G UNI I/O board for USB 3.0 and SDI
ACX288-CTL CPU board
ACX-LPCAB-EU IEC connection cable for power supply, lockable, EU power connector
ACX-LPCAB-US IEC connection cable for power supply, lockable, US power connector
ACXSFPC CATx GBIC for use with Modular KVM Matrix Switch
ACXSFPS Single-mode GBIC, LC duplex, bidirectional, for use with Modular KVM Matrix Switch
ACXSFPHS Single-mode GBIC, LC duplex, bidirectional, for use with Modular KVM Matrix Switch (3.125 Gbit/s)
ACXUSB-MM-SFP Multimode GBIC, LC duplex, bidirectional, USB 3.0 (6.25 Gbit/s), for use with Modular KVM Matrix Switch
ACX3GSDI-COAX-SFP Coaxial GBIC, bidirectional, for use with Modular KVM Matrix Switch (3G-SDI)
ACX3GSDI-DIN123-SFP DIN 1.0/2.3 GBIC, bidirectional, for use with Modular KVM Matrix Switch (3G-SDI)
ACX3GSDI-SM-SFP Single-mode GBIC, LC duplex, bidirectional, for use with Modular KVM Matrix Switch (3G-SDI)
ACXSDI-BNCCAB Adapter cable BNC to mini BNC to adapt regular BNC cables to mini BNC SFP
ACX288-FAN ACX288/ACX160 fan tray (spare part)
ACX080-FAN ACX080 fan tray (spare part)
ACX048-FAN ACX048 fan tray (spare part)
ACX288-PS ACX288/ACX160 plug-in power supply unit (spare part or redundancy)
ACX080-PS ACX080 plug-in power supply unit (spare part or redundancy)
ACX288-FIL ACX288, ACX160 filter pads as consumable supply
ACX080-FIL ACX080 filter pads as consumable supply
ACX048-FIL ACX048 filter pads as consumable supply
