CHAPTER 4: CONFIGURATION
7. The USB 2.0 CPU extender now has to be either assigned to an existing CON Device in the Definition > CPU Devices menu
or a new CON Device has to be created for the assignment by pressing the New button.
8. If you use parallel operation within the matrix, set the Release Time in the Configuration > Switch menu to 10 seconds or more
(see Section 4.11.6).
9. Restart all I/O boards on which USB 2.0 extenders have been configured or alternatively restart the matrix.
The USB 2.0 extenders are now configured and can be used.
NOTE: Created extender units are always set as fixed-port extenders. This configuration is necessary if you want to switch,
e.g. USB 2.0 connections via the matrix.
NOTE: To make a fixed port available again for Flex-Port extender units after deleting a fixed-port extender unit, you must restart
the I/O board.
4.8 EXTENDERS FOR UNI I/O BOARDS (USB 2.0/USB 3.0)
This section will help you to configure and use your USB 2.0/3.0 extenders. To use USB 3.0 extenders, you need at least one UNI
I/O board and SFP modules based on 6.25 Gbit/s for the matrix.
You have the following options to configure the system:
OSD
