CHAPTER 3: INSTA LL ATION
7. If you have a video matrix, connect the video source directly to the matrix using the interconnect cables (coax, fiber).
8. Connect the 5-VDC power supply units to the CPU Units.
9. Start the system.
3.3 EXAMPLE APPLICATIONS
The Modular KVM Matrix Switch supports a wide and flexible range of system configurations:
A part of the Modular KVM Matrix Switch can be configured as a Single-Head work station, a part as Dual-Head, as Quad-Head
or even as a video matrix for example. In addition to that, there are configurations with KVM and USB 2.0 available.
In addition to OSD access by a keyboard connected to the CPU board or and extender CON Unit, other methods of control
are available, including:
 Java Tool
 Serial interface
A connection to common media controls is also possible.
The following sections show typical example installations of the Modular KVM Matrix Switch.
